BRAWA 41665

• Road no.: 103 022-0
• Marklin AC Digital Extra Version
• Digital Sound
• Digital Couplers
• Doehler & Haass Decoder
• Energy Storage Installed
• Coupler pocket and close coupling
• PLUX22 Decoder Socket
• Motor with Flywheel
• Sprung Buffers
• Triple headlights and two red taillights alternating with the direction of travel
• Etched radiator grille (prototypically on models without radiator lamellas)
• Free-standing handles and handrails
• Clear view through the driver cabin
• Lights equipped with maintenance-free LEDs
• Three-point support
• Finely detailed chassis
• Finest paintwork and painting
• Reproduction of the brake linkage
• Metal frame and wheels, structure made of plastic
• NEM-standard short coupling
• Light change and driver cabin light

Digital Version EXTRA:

• Filigree electronic coupling (interchangeable due to NEM standard)*
• Incl. energy storage (buffers sound, motor and light)
• Extensive light functions: shunting lights, drivers cabin lighting, tail lights separately switchable
• Optimized lighting control for drive and shunting mode
• Flicker-free light, due to stabilized 5V power supply which is buffered through a separate capacitor
• Original sound
• Noiseless 16-bit sound with up to 8 independent channels thanks to latest sound technology and excellent sound characteristics
• Optimal motor and load control for perfect running characteristics
• Compatible with all established digital systems (DCC, Motorola, SX1 und SX2)
• Enclosed locomotive card in the AC version
• Driver cabin lighting

It is possible to retrospectively convert from analogue to digital via a PluX22 interface (only sound functions). Please note that it is not possible to retrospectively convert the digital remotecontrol coupling or the additional light functions. For retrofitting of the product variant "Basic+" we recommend the sound decoder SD22A-4 (Order no. 99801).

Overview of technical functions

	Analog Basic+ =	Digital Extra =
Driving function	•	•
Light change	•	•
Tail lights separately switchable	• 1)	•
Driver cabin lighting	• 1)	•
Shunting lights	• 1)	•
Light setting programmable for analogue operation		•
Digital interface	PluX22	PluX22
Decoder		•
Sound		•
Energy storage		• 2)
Digital coupling (NEM-standard close coupling)		•
Locomotive Card
Additional information	• Subsequent conversion from analog to digital via PluX22 interface possible	• Optimised light control for driving and shunting modes • Latest sound technology and excellent sound quality • Compatible with and programmable in all common digital systems (DCC, Motorola, SX1 and SX2) • Improved motor and load control

1) Function only available in digital mode

2) Storage capacitor for interruption-free travel in sections without current or on soiled tracks
