Product characteristics and functions of the drive decodersÂ
 Â
- For operation optionally with conventional direct-current vehicles, digital systems according to NMRA standard (DCC), SelecTRIX 1 and 2, Motorola and partly AC analogue
- Switchover between analogue to digital is automatic
- In digital mode, the system last programmed is used (no automatic switchover!)
- DCC short addresses (1-127), long addresses (0001-9999), with 14, 28, 126 speed stages
- SelecTRIX 1: 31 speed stages, 100 addresses, 16 additional functions
- SelecTRIX 2: 127 speed stages, 10,000 addresses, 16 additional functions
- Latest-generation load control for especially smooth control behaviour
- Various control types for optimal adjustment to the engine
- 127 internal speed stages
- Adjustable engine frequency (low frequency, 16 kHz,32 kHz)
- Block section operation with simple diodes in digital mode
- Light and function outputs (partly) dimmable and capable of analogue activation
- Shunting gear
- Engine, light and track connections electronically replaceable
- All function outputs freely programmable
- Temperature protection
- Reset function for DCC and SX2
- NEM 652 Digital Interface
